ELS‑380HD
The ELS‑380HD is a high‑precision industrial X‑ray foreign‑object inspection device independently developed by Dongguan Erlangshen Imaging Equipment Co., Ltd. Targeted at light‑industry sectors including footwear, luggage, apparel and toys, it detects hidden foreign objects inside finished products such as broken nails, broken needles, fine metal debris, stones and glass to eliminate product safety risks. Compared with the ELS‑360HD model, it delivers superior imaging resolution and detection sensitivity, and is designed for high‑precision inspection scenarios.
Core Features
1. Ultra‑high‑definition Imaging: Equipped with original Japanese CMOS sensor, it offers 2.5D inspection performance and an eagle‑eye partial zoom function for sharp, detailed imaging of tiny foreign objects.
2. High Detection Sensitivity: Capable of identifying metal spheres as small as 0.4 mm in diameter, as well as fine broken needle tips and trace metal contaminants.
3. Conveying Performance: Maximum belt speed of 12 m/min with an output capacity of approximately 600 pieces per hour. It supports intelligent front‑end queuing feeding, and switches between automatic and single‑piece conveying modes to adapt to assembly‑line operations.
4. Inspection Aperture: Standard aperture dimension: 500 mm (W) × 230 mm (H); custom‑built apertures are available upon request.
5. Radiation Safety: Radiation leakage is far below international safety limits to ensure operator safety.
6. Stable X‑ray Source: Fitted with original American X‑ray tube with adjustable voltage and current, enabling long‑duration continuous production.
Traceability Management Software
Embedded DSP intelligent image‑processing system with operator authority management. Optional image printing and barcode printing functions are available. Barcodes can be edited with model numbers, serial numbers, production time and customer information to realize full‑process quality traceability. Images can be displayed in multiple modes: black‑and‑white, color and reverse‑color.
The ELS‑380HD is a high‑precision industrial X‑ray foreign‑object inspection device independently developed by Dongguan Erlangshen Imaging Equipment Co., Ltd. Targeted at light‑industry sectors including footwear, luggage, apparel and toys, it detects hidden foreign objects inside finished products such as broken nails, broken needles, fine metal debris, stones and glass to eliminate product safety risks. Compared with the ELS‑360HD model, it delivers superior imaging resolution and detection sensitivity, and is designed for high‑precision inspection scenarios.
Core Features
1. Ultra‑high‑definition Imaging: Equipped with original Japanese CMOS sensor, it offers 2.5D inspection performance and an eagle‑eye partial zoom function for sharp, detailed imaging of tiny foreign objects.
2. High Detection Sensitivity: Capable of identifying metal spheres as small as 0.4 mm in diameter, as well as fine broken needle tips and trace metal contaminants.
3. Conveying Performance: Maximum belt speed of 12 m/min with an output capacity of approximately 600 pieces per hour. It supports intelligent front‑end queuing feeding, and switches between automatic and single‑piece conveying modes to adapt to assembly‑line operations.
4. Inspection Aperture: Standard aperture dimension: 500 mm (W) × 230 mm (H); custom‑built apertures are available upon request.
5. Radiation Safety: Radiation leakage is far below international safety limits to ensure operator safety.
6. Stable X‑ray Source: Fitted with original American X‑ray tube with adjustable voltage and current, enabling long‑duration continuous production.
Traceability Management Software
Embedded DSP intelligent image‑processing system with operator authority management. Optional image printing and barcode printing functions are available. Barcodes can be edited with model numbers, serial numbers, production time and customer information to realize full‑process quality traceability. Images can be displayed in multiple modes: black‑and‑white, color and reverse‑color.
